Input voltage range: | AC 100~240V / DC 10~34V |
Max input current: | DC 35A |
Output voltage range: | DC 1~34V |
Charging current: | 0.2~20A x2 |
Discharge current: | 0.2~1.5A x2 |
Balance current: | 1.5A/Cell Max |
Maximum charging power: | AC 200W / DC 500W x2 |
Maximum discharge power: | 15W x2 |
Supported battery types and cell count: | LiFe; Lilon; LiPo 1~8S; LiHv,ULiHv 1~7S; Pb 1~14S; NiMH/Cd 1~18S |
Parallel charging power and current: | 800W/30A |
Parallel discharge power and current: | 30W/3A |
Battery voltage abnormal alarm: | Supported |
String number setting error alarm: | Supported |
Operating temperature: | 0~40℃ |
USB-C1: | PD 65W |
USB-C2: | PD 65W |
Storage temperature: | -20℃~60℃ |
Size: | 135x126x57.7mm |
Weight: | About 776g |
